30kVA Dry type transformer
The 30kVA Dry type transformer complies with ANSI, CSA, NEMA, IEEE, IEC, GB, and DOE standards. NPC ELECTRIC manufactures Dry type transformer in strict accordance with the highest industry and international standards. Our team of highly skilled professionals ensures these rigorous standards are meticulously upheld in daily operations.
- Primary Voltage Ratings 34.5-19.92/13.8-7.957/13.2-7.62/12.47-7.2, 24.94, 26.25, 33 or others
- Secondary Voltage Ratings 480/277V,400/230V,380/220V or customized
- H.V. Tap Range ± 2×2.5% HV taps or others
- Type Dry type transformer
- BIL 30/95kV
- Standards IEEE, ANSI, NEMA,IEC,GB
- Application High-rise buildings, commercial centers, theaters, hospitals, hotels etc.
- Power Rating 30kVA
- Certificate UL ,CESI
- Cooling Method OA/OF
- Opeartion Step Down & Step Up
Technical Specifications
Core Features
Packing and Shipping
Transformer Manufacturer Progress Test
Routine Test
Application
Technical Specifications
30kVA Dry type transformer
Technical Specifications
Accessories
| Technical Specifications | ||
| Rated Power | 30 kVA | |
| Rating Primary Voltage | 2.4-34.5kV | |
| Secondary Voltage | 480/277V 400/230V 380/220V Customized |
|
| Frequency | 50/60Hz | |
| Vector Group | Dyn11,Yyn0,Dyn5 | |
| Winding Material | Aluminum/Copper | |
| Efficiency | As IEEE,Doe 2016,CAS Std or Customized | |
| Impedance Voltage | Nominal 2% or Customized 1.1-5.75% | |
| Altitude | ≤1,000m or Customized | |
| Enclosure material | 304 Stainless Steel | |
| Insulating Oil Weight | 30 kg | |
| Total Weight | 250 kg | |
| Outline Dimensions（L×W×H）in. | 700×500×900（mm) | |
| HV Bushing |
| LV Bushing |
| Tap changer connector |
| Lifting hook for complete transformer |
| Name plate |
Core Features
30kVA Dry type transformer
Our transformers offer a range of core features designed to meet diverse application needs and ensure reliable performance. With custom-design flexibility, we tailor solutions to specific customer requirements and load profiles using computerized, loss-evaluated design methods. Built with robust construction for high short-circuit strength, they also feature low maintenance and enhanced environmental protection through advanced coating techniques.
For added reliability, a fan cooling package with digital winding temperature monitoring is included. All products comply with key industry standards, including NEMA No. 201-1982, NEMA ST-20, IEEE No. 100-1977, IEEE C57.12.01, and IEEE C57.12.91.
Packing and Shipping
30kVA Dry type transformer
NPC ELECTRIC’s dry-type transformers are meticulously packaged for secure sea freight and long-distance transport, ensuring they arrive at their destination in perfect condition and ready for installation. For a 30kVA dry-type transformer, the packing and shipping process is carefully engineered to minimize the risk of damage during transit.
Each transformer is enclosed in a durable, weather-resistant wooden crate or steel-reinforced container, with internal cushioning materials such as high-density foam or shock-absorbing padding to protect against vibration, impact, and shifting. The packaging is designed to shield the transformer from moisture, dust, and other environmental factors that could compromise performance.
During shipping—whether by road, rail, or sea—the transformer is securely fastened to a pallet or transport platform using heavy-duty straps or tie-downs to prevent movement. Clear handling instructions, safety warnings, and directional indicators are prominently displayed on the packaging to ensure proper handling by logistics personnel.
All necessary shipping documentation is provided, including customs clearance paperwork, certificates of origin, and any required permits, ensuring full compliance with international transport regulations. Upon delivery, a thorough visual inspection is conducted to verify the transformer's integrity before installation.
This comprehensive packing and shipping process guarantees that the 30kVA dry-type transformer arrives safely and in optimal working condition, ready for reliable, long-term operation.
Each transformer is enclosed in a durable, weather-resistant wooden crate or steel-reinforced container, with internal cushioning materials such as high-density foam or shock-absorbing padding to protect against vibration, impact, and shifting. The packaging is designed to shield the transformer from moisture, dust, and other environmental factors that could compromise performance.
During shipping—whether by road, rail, or sea—the transformer is securely fastened to a pallet or transport platform using heavy-duty straps or tie-downs to prevent movement. Clear handling instructions, safety warnings, and directional indicators are prominently displayed on the packaging to ensure proper handling by logistics personnel.
All necessary shipping documentation is provided, including customs clearance paperwork, certificates of origin, and any required permits, ensuring full compliance with international transport regulations. Upon delivery, a thorough visual inspection is conducted to verify the transformer's integrity before installation.
This comprehensive packing and shipping process guarantees that the 30kVA dry-type transformer arrives safely and in optimal working condition, ready for reliable, long-term operation.
32
32 years of industry experience
Transformer Manufacturer Progress Test
30kVA Dry type transformer
Progress test
NPC Electric manufactures high-quality three-phase dry-type transformers under strict quality control protocols. During production, a comprehensive Progress Test is conducted on each 30kVA unit to ensure full compliance with design specifications and quality standards. This process includes verification of core insulation, winding resistance, and dielectric strength. Key electrical components such as bushings, tap changers, and protection devices are also tested to confirm proper functionality. The transformer’s ability to withstand operational loads and voltage fluctuations is thoroughly assessed. Any deviations or issues identified are promptly addressed before proceeding to final testing. These rigorous progress tests ensure that every dry-type transformer delivered is safe, reliable, and fully prepared for real-world operation, while meeting all relevant industry standards.
Design Tests
All transformer will be test after finished the production, test items as below:
♦ Insulation Power Factor:
♦ Ratio, Polarity, and Phase Relation:
♦ Winding Resistance:
♦ Impulse Tests:
♦ On load Loss Test:
♦ No Load Loss Test
♦ Leak Test:
♦ DC Insulation Resistance Test
♦ Transformer Turns Ratio/TTR (All Tap Voltages)
♦ Impedance Voltage & Load Loss (Rated Voltage)
♦ Polarity, 1-Ph / Phase Relation, 3-Ph (Rated Voltage)
♦ Excitation & No-Load Loss (Rated Voltage)
♦ Applied Voltage
♦ Induced Voltage
♦ Lightning Impulse
♦ Insulation Resistance (Rated Voltage)
♦ Temperature Rise
♦ Dielectric Withstand (Hipot)
♦ Insulation Power Factor:
♦ Ratio, Polarity, and Phase Relation:
♦ Winding Resistance:
♦ Impulse Tests:
♦ On load Loss Test:
♦ No Load Loss Test
♦ Leak Test:
♦ DC Insulation Resistance Test
♦ Transformer Turns Ratio/TTR (All Tap Voltages)
♦ Impedance Voltage & Load Loss (Rated Voltage)
♦ Polarity, 1-Ph / Phase Relation, 3-Ph (Rated Voltage)
♦ Excitation & No-Load Loss (Rated Voltage)
♦ Applied Voltage
♦ Induced Voltage
♦ Lightning Impulse
♦ Insulation Resistance (Rated Voltage)
♦ Temperature Rise
♦ Dielectric Withstand (Hipot)
Transformer Factory Acceptance Test
NPC Electric conducts rigorous quality control testing on every transformer or representative samples, as well as on specific components and materials, to ensure compliance with design specifications throughout the production process.
The Factory Acceptance Test (FAT) for a 30kVA three-phase dry-type transformer is a critical step performed before shipment to verify that the unit meets all applicable standards and delivers optimal performance. The FAT includes the following key procedures:
Visual Inspection: Evaluates the transformer’s physical condition, including the enclosure, terminals, and labeling, to ensure conformance with design and safety requirements.
Electrical Testing: Involves measuring winding resistance, insulation resistance, and performing turns ratio tests to validate electrical integrity and functionality.
Dielectric Strength Test: Applies high voltage across the insulation system to ensure it can endure both normal and transient operating voltages without failure.
Load Testing: Simulates real-world operating conditions to assess the transformer’s voltage regulation, temperature rise, and overall efficiency under load.
Protection Device Testing: Verifies the proper operation of integrated protective components such as thermal sensors, temperature relays, and tap changers (if applicable).
These comprehensive tests ensure that each 30kVA dry-type transformer is safe, reliable, and fully compliant with industry standards, providing peace of mind before delivery and installation.
The Factory Acceptance Test (FAT) for a 30kVA three-phase dry-type transformer is a critical step performed before shipment to verify that the unit meets all applicable standards and delivers optimal performance. The FAT includes the following key procedures:
Visual Inspection: Evaluates the transformer’s physical condition, including the enclosure, terminals, and labeling, to ensure conformance with design and safety requirements.
Electrical Testing: Involves measuring winding resistance, insulation resistance, and performing turns ratio tests to validate electrical integrity and functionality.
Dielectric Strength Test: Applies high voltage across the insulation system to ensure it can endure both normal and transient operating voltages without failure.
Load Testing: Simulates real-world operating conditions to assess the transformer’s voltage regulation, temperature rise, and overall efficiency under load.
Protection Device Testing: Verifies the proper operation of integrated protective components such as thermal sensors, temperature relays, and tap changers (if applicable).
These comprehensive tests ensure that each 30kVA dry-type transformer is safe, reliable, and fully compliant with industry standards, providing peace of mind before delivery and installation.
Routine Test
Insulation Power Factor
Ratio, Polarity, and Phase Relation
Winding Resistance
Impulse Tests
On load Loss Test
No Load Loss Test
Test standard as below:
IEEE C57.12.00 & IEEE C57.12.90 (Liquid-Immersed)
IEEE C57.12.01 & IEEE C57.12.91 (Dry-Type)
IEEE C57.12.01 & IEEE C57.12.91 (Dry-Type)
*These comprehensive tests ensure that each transformer meets performance standards and operates reliably under various conditions.
Application
High-rise buildings, commercial centers, theaters, hospitals, hotels etc.
Factory View
● 30+ years of manufacturing experience
● ISO and UL certified production
● Customized cable and transformer solutions
Product Packaging
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Packaging and delivery site
Related Products
FAQ From Customers
-
What is a Transformer?A transformer is an electrical device used to change the voltage of alternating current (AC). It works on the principle of electromagnetic induction, converting high-voltage current into low-voltage current or low-voltage current into high-voltage current. Transformers are widely used in power transmission, distribution systems, and various electronic devices.
-
What are the main uses of a transformer?The main use of a transformer is voltage conversion. Transformers are used in power transmission systems to help transfer electricity from power plants to consumers. In addition, transformers are also used in electronic devices such as chargers, televisions, power adapters, etc., to adjust the voltage to meet the requirements of different devices.
-
Do you have UL listed?Yes, our transformer has UL listed. We have exported to America many pad mounted transformer,substation transformer and HV.
